摘要：
雄安新区某污水处理厂提标改造工程，要求出水水质由《城镇污水处理厂污染物排放标准》（GB 18918—2002）一级A标准提升至《地表水环境质量标准》（GB 3838—2002）中Ⅳ类水质标准，其中出水TN≤10 mg/L。该工程通过将污水厂原有的悬链式曝气+A2/O工艺改造为BioDopp工艺，最终实现污水厂出水COD、氨氮、TN、TP等各项水质指标达到当地规定的准Ⅳ类水质标准。该工程采用内部改造的方式，不仅节约用地、节省造价，且出水TN稳定<10 mg/L，可为同类型用地紧张污水厂提标改造工程提供方案借鉴。
关键词:
BioDopp,
提标改造,
准Ⅳ类水体
Abstract:
The effluent quality standard is required to raise from class A water quality standard in the Discharge Standard of Pollutants for Municipal Wasterwater Treatment Plant（GB 18918—2002）to class Ⅳ standard in the Environment Quality Standards for Surface Water（GB 3838—2002）for a sewage treatment plant in Xiong’an New District，in which the effluent TN is required to be less than 10 mg/L. The project transformed the original catenary aeration A2/O process into a BioDopp process，and finally realized that the effluent COD，NH4 +-N，TN，TP and other water quality indexes reached the local standard of class Ⅳ water quality. This project adopted the method of internal transformation，which not only saved land and cost，but also the effluent TN was stable less than 10 mg/L. This project provided a reference for the upgrading project of the same type of intensive sewage plant.
Key words:
BioDopp,
upgrading and reconstruction,
quasi-Ⅳ water body
中图分类号:
刘平波, 张俊, 王家乐, 汪辉, 赵耀. BioDopp工艺应用于污水厂提标改造工程实例探讨[J]. 工业水处理, 2022, 42(1): 163-166.
Pingbo LIU, Jun ZHANG, Jiale WANG, Hui WANG, Yao ZHAO. Case analysis on the application of BioDopp technology in upgrading of sewage treatment[J]. Industrial Water Treatment, 2022, 42(1): 163-166.
