Construction of an efficient ammonia nitrogen removal bacterial community and its application under weakly acidic conditions

doi:10.19965/j.cnki.iwt.2023-0377

Abstract

Abstract:

Biological nitrogen removal technology has bottlenecks such as long start-up time and low efficiency in the process of high ammonia nitrogen wastewater treatment due to the specificity of wastewater, while the screened single high-efficiency nitrogen removal strain suffers from poor stability in the actual wastewater treatment process. In this study, based on the screening of a large number of highly efficient heterotrophic nitrification- aerobic denitrification strains,the core strains 139^# and 142^# were identified through partial factorial experiments, and the strain combinations were optimized by combining metabolic correlation and stratified sampling methods to artificially construct an efficient nitrogen removal community. The optimum combination of strains was obtained by re-screening with sludge at pH 5.5, and the ability of the constructed community for nitrogen removal was verified by using a reactor to simulate weak acidic wastewater treatment. The results showed that the screened high-efficiency bacterial community P44-P83-A88-P94-A142 achieved 96.97% removal of NH₄ ⁺-N at 48 h under the condition of initial NH₄ ⁺-N mass concentration of 200 mg/L and initial pH of 5.5. Within the reactor to simulate the actual wastewater environment, the addition of the bacteria at a weakly acidic pH of 5.5 increased the removal rate of NH₄ ⁺-N from 44.89% to 75.17% and the effluent pH from 6.9 to 8.3. This study can provide a theoretical basis for the application of artificially constructed bacterial community in the treatment of weakly acidic wastewater for nitrogen removal.

Key words: biological nitrogen removal, partial factorial experiment, high-efficiency nitrogen removal community, weakly acidic wastewater

摘要：

生物脱氮技术在高氨氮废水处理过程中因废水的水质特异性问题存在启动时间长、脱氮效率低等瓶颈，而筛选的单一高效脱氮菌株在实际废水处理过程中也存在稳定性差的问题。在筛选出大量高效异养硝化-好氧反硝化菌株的基础上，通过部分因子实验确定了核心菌株139^#和142^#，结合代谢关联与分层抽样方法优化菌株组合，人工构建高效脱氮菌群，在pH为5.5的条件下与污泥混合培养复筛得到了最佳菌群组合，最终采用反应器模拟弱酸性废水处理实验对构建菌群的脱氮能力进行了验证。结果表明：筛选出的高效菌群P44-P83-A88-P94-A142在初始NH₄ ⁺-N质量浓度为200 mg/L，初始pH为5.5的条件下，48 h时对NH₄ ⁺-N的去除率达到96.97%；利用反应器模拟实际废水环境，在pH为5.5的弱酸性条件下，加入该菌群使得体系对NH₄ ⁺-N的去除率从44.89%提升到了75.17%，出水pH从6.9左右提高到了8.3左右。该研究可为人工构建菌群在弱酸性废水脱氮处理中的应用提供理论依据。

关键词: 生物脱氮, 部分因子实验, 高效脱氮菌群, 弱酸性废水

CLC Number:

X703.1

Jiajing CHEN, Xiaojun FAN, Ke YUAN, Yun DUAN, Jin YUAN. Construction of an efficient ammonia nitrogen removal bacterial community and its application under weakly acidic conditions[J]. Industrial Water Treatment, 2024, 44(5): 71-79.

陈佳婧, 范晓军, 袁可, 端允, 袁进. 高效氨氮去除菌群构建及其在弱酸性条件下的应用[J]. 工业水处理, 2024, 44(5): 71-79.

/ / Recommend / Download Citations

URL: https://www.iwt.cn/EN/10.19965/j.cnki.iwt.2023-0377

https://www.iwt.cn/EN/Y2024/V44/I5/71

Figures/Tables 14

References 30

1	MISHRA S， SINGH V， CHENG Liu，et al. Nitrogen removal from wastewater：A comprehensive review of biological nitrogen removal processes，critical operation parameters and bioreactor design［J］. Journal of Environmental Chemical Engineering，2022，10（3）：107387. doi:10.1016/j.jece.2022.107387
2	REN Xinghao， WANG Yan， WAN Jinquan，et al. The nitrogen removal performance and functional bacteria in heterotrophic denitrification and mixotrophic denitrification process［J］. Water，2022，14（22）：3603. doi:10.3390/w14223603
3	WU Tong， YANG Shanshan， ZHONG Le，et al. Simultaneous nitrification，denitrification and phosphorus removal：What have we done so far and how do we need to do in the future？［J］. Science of the Total Environment，2023，856：158977. doi:10.1016/j.scitotenv.2022.158977
4	WANG Teng， DANG Qifeng， LIU Chengsheng，et al. Heterotrophic nitrogen removal by a newly-isolated alkalitolerant microorganism，Serratia marcescens W5［J］. Bioresource Technology，2016，211：618-627. doi:10.1016/j.biortech.2016.03.142
5	剧盼盼，刘洪泉，刘斌，等. 焦化废水含氮污染物分析与控制研究进展［J］. 工业水处理，2022，42（11）：40-45.
	JU Panpan， LIU Hongquan， LIU Bin，et al. Research progress on analysis and control of nitrogencontaining pollutants in coking wastewater［J］. Industrial Water Treatment，2022，42（11）：40-45.
6	张怡鸣，张玉秀，祖德彪，等. 焦化废水处理技术及其污泥细菌菌群结构功能研究进展［J］. 矿业科学学报，2020，5（2）：232-241.
	ZHANG Yiming， ZHANG Yuxiu， ZU Debiao，et al. Coking wastewater treatment technology and its bacterial community structure and function in sludge［J］. Journal of Mining Science and Technology，2020，5（2）：232-241.
7	ROBERTSON L A， KUENEN J G. Thiosphaera pantotropha gen. nov.sp. nov.，a facultatively anaerobic，facultatively autotrophic sulphur bacterium［J］. Microbiology，1983，129（9）：2847-2855. doi:10.1099/00221287-129-9-2847
8	ZHANG Xiaoying， XIA Yuxiang， ZENG Yiwei，et al. Simultaneous nitrification and denitrification by Pseudomonas sp. Y-5 in a high nitrogen environment［J］. Environmental Science and Pollution Research，2022，29（46）：69491-69501. doi:10.1007/s11356-022-20708-x
9	XU Na， LIAO Min， LIANG Yuqi，et al. Biological nitrogen removal capability and pathways analysis of a novel low C/N ratio heterotrophic nitrifying and aerobic denitrifying bacterium（Bacillus thuringiensis strain WXN-23）［J］. Environmental Research，2021，195：110797. doi:10.1016/j.envres.2021.110797
10	HE Tengxia， LI Zhenlun， SUN Quan，et al. Heterotrophic nitrification and aerobic denitrification by Pseudomonas tolaasii Y-11 without nitrite accumulation during nitrogen conversion［J］. Bioresource Technology，2016，200：493-499. doi:10.1016/j.biortech.2015.10.064
11	CHEN Junli， XU Juan， ZHANG Shunan，et al. Nitrogen removal characteristics of a novel heterotrophic nitrification and aerobic denitrification bacteria，Alcaligenes faecalis strain WT14［J］. Journal of Environmental Management，2021，282：111961. doi:10.1016/j.jenvman.2021.111961
12	ZHOU Xiangqun， WANG Yuanli， TAN Xin，et al. Genomics and nitrogen metabolic characteristics of a novel heterotrophic nitrifying-aerobic denitrifying bacterium Acinetobacter oleivorans AHP123［J］. Bioresource Technology，2023，375：128822. doi:10.1016/j.biortech.2023.128822
13	XI Haipeng， ZHOU Xiangtong， ARSLAN M，et al. Heterotrophic nitrification and aerobic denitrification process：Promising but a long way to go in the wastewater treatment［J］. Science of the Total Environment，2022，805：150212. doi:10.1016/j.scitotenv.2021.150212
14	ZENG Xiaoying， HUANG Jinhui， HUA Binbin，et al. Nitrogen removal bacterial strains，MSNA-1 and MSD4，with wide ranges of salinity and pH resistances［J］. Bioresource Technology，2020，310：123309. doi:10.1016/j.biortech.2020.123309
15	ZHAO Tiantao， CHEN Peipei， ZHANG Lijie，et al. Heterotrophic nitrification and aerobic denitrification by a novel Acinetobacter sp.TAC-1 at low temperature and high ammonia nitrogen［J］. Bioresource Technology，2021，339：125620. doi:10.1016/j.biortech.2021.125620
16	HE Xiaoling， SUN Qi， XU Tengyao，et al. Removal of nitrogen by heterotrophic nitrification-aerobic denitrification of a novel halotolerant bacterium Pseudomonas mendocina TJPU04［J］. Bioprocess and Biosystems Engineering，2019，42（5）：853-866. doi:10.1007/s00449-019-02088-8
17	CHEN Xue， ZHANG Qian， ZHU Yunan，et al. Response of wastewater treatment performance，microbial composition and functional genes to different C/N ratios and carrier types in MBBR inoculated with heterotrophic nitrification-aerobic denitrification bacteria［J］. Bioresource Technology，2021，336：125339. doi:10.1016/j.biortech.2021.125339
18	CHEN Hong， LIU Ke， YANG Enzhe，et al. A critical review on microbial ecology in the novel biological nitrogen removal process：Dynamic balance of complex functional microbes for nitrogen removal［J］. Science of the Total Environment，2023，857：159462. doi:10.1016/j.scitotenv.2022.159462
19	ZHANG Haihan， SHI Yinjie， MA Ben，et al. Mix-cultured aerobic denitrifying bacteria augmented carbon and nitrogen removal for micro-polluted water：Metabolic activity，coexistence and interactions，and immobilized bacteria for reservoir raw water treatment［J］. Science of the Total Environment，2022，838：156475. doi:10.1016/j.scitotenv.2022.156475
20	朱彤，吴边. 合成微生物组：当“合成生物学”遇见“微生物组学”［J］. 科学通报，2019，64（17）：1791-1798. doi:10.1360/n972018-01194
	ZHU Tong， WU Bian. Synthetic microbiome：When “synthetic biology” meets “microbiomics”［J］. Chinese Science Bulletin，2019，64（17）：1791-1798. doi:10.1360/n972018-01194
21	WIDDER S， ALLEN R J， PFEIFFER T，et al. Challenges in microbial ecology：Building predictive understanding of community function and dynamics［J］. The ISME Journal，2016，10（11）：2557-2568. doi:10.1038/ismej.2016.45
22	徐昭勇，胡海洋，许平，等. 人工合成微生物组的构建与应用［J］. 合成生物学，2021，2（2）：181-193.
	XU Zhaoyong， HU Haiyang， XU Ping，et al. Development and application of synthetic microbiome［J］. Synthetic Biology Journal，2021，2（2）：181-193.
23	吕永康，殷家红，刘玉香，等. 一株异养硝化菌的分离鉴定及其最佳亚硝化条件［J］. 化工学报，2011，62（5）：1421-1427. doi:10.3969/j.issn.0438-1157.2011.05.036
	Yongkang LÜ， YIN Jiahong， LIU Yuxiang，et al. Isolation and identification of a heterotrophic nitrifier and its optimal conditions for nitrification［J］. CIESC Journal，2011，62（5）：1421-1427. doi:10.3969/j.issn.0438-1157.2011.05.036
24	李玉娇，刘玉，陈洪雷. APMP废水生物降解菌群的构建［J］. 中国造纸，2016，35（1）：36-41. doi:10.11980/j.issn.0254-508X.2016.01.007
	LI Yujiao， LIU Yu， CHEN Honglei. The construction of micro flora for degrading APMP effluent［J］. China Pulp & Paper，2016，35（1）：36-41. doi:10.11980/j.issn.0254-508X.2016.01.007
25	YANG Jingrui， WANG Ying， CHEN Hu，et al. Ammonium removal characteristics of an acid-resistant bacterium Acinetobacter sp.JR1 from pharmaceutical wastewater capable of heterotrophic nitrification-aerobic denitrification［J］. Bioresource Technology，2019，274：56-64. doi:10.1016/j.biortech.2018.10.052
26	邹玉兰，王莹，陈虎，等. 恶劣环境下异养硝化-好氧反硝化菌的研究进展［J］. 工业水处理，2020，40（12）：8-13.
	ZOU Yulan， WANG Ying， CHEN Hu，et al. Research progress of heterotrophic nitrification-aerobic denitrification bacteria in harsh environment［J］. Industrial Water Treatment，2020，40（12）：8-13.
27	何环，余萱，韩亚涛，等. 异养硝化好氧反硝化菌脱氮特性的研究进展［J］. 工业水处理，2017，37（4）：12-17. doi:10.11894/1005-829x.2017.37(4).003
	HE Huan， YU Xuan， HAN Yatao，et al. Research progress in the denitrification characteristics of heterotrophic nitrification-aerobic denitrification bacteria［J］.Industrial Water Treatment，2017，37（4）：12-17. doi:10.11894/1005-829x.2017.37(4).003
28	YANG Chao， ZHANG Wei， LIU Ruihua，et al. Phylogenetic diversity and metabolic potential of activated sludge microbial communities in full-scale wastewater treatment plants［J］. Environmental Science & Technology，2011，45（17）：7408-7415. doi:10.1021/es2010545
29	黄涵，王继华. 污水处理厂中微生物群落特性与基因功能探究［J］. 环境科学与技术，2023，46（S1）：1-7.
	HUANG Han， WANG Jihua. Study on characteristics and functions of microbial community in urban sewage treatment plant［J］. Environmental Science & Technology，2023，46（S1）：1-7.
30	高春娣，赵楠，安冉，等. FNA对短程硝化污泥菌群结构的影响［J］. 中国环境科学，2019，39（5）：1977-1984. doi:10.3969/j.issn.1000-6923.2019.05.022
	GAO Chundi， ZHAO Nan， AN Ran，et al. Effect of FNA on microorganism community structures of partial nitrification sludge［J］. China Environmental Science，2019，39（5）：1977-1984. doi:10.3969/j.issn.1000-6923.2019.05.022

编号	NH₄ ⁺-N去除率/%	编号	NH₄ ⁺-N去除率/%
44	77.61	94	71.53
83	64.96	127	67.99
87	70.62	135	64.84
88	74.40	139	78.35
89	65.63	142	76.73

编号	NH₄ ⁺-N去除率/%	编号	NH₄ ⁺-N去除率/%
44	77.61	94	71.53
83	64.96	127	67.99
87	70.62	135	64.84
88	74.40	139	78.35
89	65.63	142	76.73

序号	变量										R/%
	A	B	C	D	E	F	G	H	J	K
	44	83	87	88	89	94	127	135	139	142
1	1	1	0	0	1	1	0	0	1	1	81.67
2	0	1	1	0	0	1	1	0	0	1	93.61
3	0	1	1	0	1	1	0	1	1	0	71.64
4	1	1	1	1	1	1	1	1	1	1	70.14
5	0	0	1	1	0	1	0	0	0	0	95.02
6	1	1	1	1	0	1	0	0	0	0	60.68
7	0	0	0	0	0	1	1	1	1	1	96.99
8	0	0	1	0	0	0	0	1	0	0	58.29
9	1	0	1	1	0	0	1	1	0	1	56.84
10	1	1	0	1	0	0	1	0	1	1	89.15
11	0	1	0	1	1	1	1	0	1	0	89.56
12	1	0	0	1	1	1	1	0	0	1	92.94
13	0	1	0	1	0	1	0	1	0	1	71.12
14	1	1	0	0	0	1	1	1	0	0	50.14
15	1	0	0	0	1	0	1	1	1	0	67.90
16	0	0	0	1	0	0	1	0	0	0	12.85
17	1	1	0	1	1	0	0	1	0	0	49.31
18	0	1	1	1	1	0	0	0	0	1	54.55
19	1	0	1	0	1	1	0	1	0	1	62.24
20	0	0	1	0	1	1	0	1	0	1	93.41
21	0	0	0	0	1	1	0	0	0	0	72.89
22	0	0	1	1	1	1	1	1	0	0	91.90
23	1	0	1	0	0	1	1	0	1	0	65.62
24	1	0	1	1	1	0	0	0	1	0	72.53
25	0	1	0	0	0	0	0	0	1	0	79.28
26	0	1	1	1	0	0	1	1	1	0	86.39
27	0	0	0	1	1	0	0	1	1	1	55.33
28	1	0	0	1	0	1	0	1	1	0	77.62
29	1	0	0	0	0	0	0	0	0	1	77.93
30	1	1	1	0	0	0	0	1	1	1	74.50
31	0	1	0	0	1	0	1	1	0	1	96.47
32	1	1	1	0	1	0	1	0	0	0	49.83

序号	变量										R/%
	A	B	C	D	E	F	G	H	J	K
	44	83	87	88	89	94	127	135	139	142
1	1	1	0	0	1	1	0	0	1	1	81.67
2	0	1	1	0	0	1	1	0	0	1	93.61
3	0	1	1	0	1	1	0	1	1	0	71.64
4	1	1	1	1	1	1	1	1	1	1	70.14
5	0	0	1	1	0	1	0	0	0	0	95.02
6	1	1	1	1	0	1	0	0	0	0	60.68
7	0	0	0	0	0	1	1	1	1	1	96.99
8	0	0	1	0	0	0	0	1	0	0	58.29
9	1	0	1	1	0	0	1	1	0	1	56.84
10	1	1	0	1	0	0	1	0	1	1	89.15
11	0	1	0	1	1	1	1	0	1	0	89.56
12	1	0	0	1	1	1	1	0	0	1	92.94
13	0	1	0	1	0	1	0	1	0	1	71.12
14	1	1	0	0	0	1	1	1	0	0	50.14
15	1	0	0	0	1	0	1	1	1	0	67.90
16	0	0	0	1	0	0	1	0	0	0	12.85
17	1	1	0	1	1	0	0	1	0	0	49.31
18	0	1	1	1	1	0	0	0	0	1	54.55
19	1	0	1	0	1	1	0	1	0	1	62.24
20	0	0	1	0	1	1	0	1	0	1	93.41
21	0	0	0	0	1	1	0	0	0	0	72.89
22	0	0	1	1	1	1	1	1	0	0	91.90
23	1	0	1	0	0	1	1	0	1	0	65.62
24	1	0	1	1	1	0	0	0	1	0	72.53
25	0	1	0	0	0	0	0	0	1	0	79.28
26	0	1	1	1	0	0	1	1	1	0	86.39
27	0	0	0	1	1	0	0	1	1	1	55.33
28	1	0	0	1	0	1	0	1	1	0	77.62
29	1	0	0	0	0	0	0	0	0	1	77.93
30	1	1	1	0	0	0	0	1	1	1	74.50
31	0	1	0	0	1	0	1	1	0	1	96.47
32	1	1	1	0	1	0	1	0	0	0	49.83

菌株序号	NCBI登录号	最高相似度菌种	相似度/%	重命名
44	OQ586454	Pseudomonas sp.	99	TYF-CJ-P44
83	OQ586455	Pseudomonas protegens	95	TYF-CJ-P83
88	OQ586456	Alcaligenes faecalis	96	TYF-CJ-A88
94	OQ586457	Pseudomonas sp.	97	TYF-CJ-P94
142	OQ586458	Acinetobacter baumannii	97	TYF-CJ-A142
