Industrial Water Treatment ›› 2023, Vol. 43 ›› Issue (11): 161-166. doi: 10.19965/j.cnki.iwt.2022-1165

• RESEARCH AND EXPERIMENT • Previous Articles     Next Articles

Adsorption properties of cross-linked starch supported magnesium hydroxide composite for Cu2+

Haihua LI1,2(), Yuhua GAO1,2, Yuxuan ZHENG1, Na LI3, Lihui ZHANG1,2, Zhenfa LIU1

  1. 1. Institute of Energy Sources, Hebei Academy of Sciences, Shijiazhuang 050081, China
    2. Hebei Technological Innovation Center for Water Saving in Industry, Shijiazhuang 050081, China
    3. Hebei Sunwater Water Treatment Co. , Ltd. , Shijiazhuang 050081, China
  • Received:2023-08-16 Online:2023-11-20 Published:2023-11-21

交联淀粉负载氢氧化镁复合材料对Cu2+的吸附性能

李海花1,2(), 高玉华1,2, 郑玉轩1, 李娜3, 张利辉1,2, 刘振法1

  1. 1. 河北省科学院能源研究所,河北 石家庄 050081
    2. 河北省工业节水技术创新中心,河北 石家庄 050081
    3. 河北桑沃特水处理有限责任公司,河北 石家庄 050081
  • 作者简介:

    李海花(1979— ),博士,副研究员。E-mail:

  • 基金资助:
    河北省科学院科技计划项目(23A09)

Abstract:

A composite of cross-linked starch supported magnesium hydroxide ISt-Mg(OH)2 was synthesized with cross-linked starch and MgSO4·7H2O as raw material and NaOH as alkalizing agent. It was characterized by FTIR,SEM,EDS and XRD,and used for the adsorption removal of Cu2+ in simulated wastewater. The effects of factors such as dosage,pH,initial concentration of Cu2+ on the adsorption properties of ISt-Mg(OH)2 were investigated. The results showed that when the mass concentration of Cu2+ was 20 mg/L,pH=5.45,the dosage of ISt-Mg(OH)2 was 300 mg/L,and the adsorption temperature was 25 ℃,the removal rate of Cu2+ could reach 91.7%. The fitting results of adsorption isotherm showed that the adsorption process of Cu2+ in water by ISt-Mg(OH)2 conformed to the Langmuir adsorption model and belonged to monolayer adsorption. At 25 ℃,the fitting saturated adsorption capacity was 82.78 mg/g. The fitting results of adsorption kinetic datas showed that the adsorption process conformed to the quasi second order kinetic model and belonged to chemical adsorption. When ISt-Mg(OH)2 was applied to treat the electroplating wastewater with Cu2+ mass concentration of 15.20 mg/L and pH=5.45,the removal rate of Cu2+ could reach more than 90%,and it was a promising adsorbent for heavy metal ions.

Key words: cross-linked starch, magnesium hydroxide, heavy mental ions, adsorption, adsorption mechanism

摘要:

以交联淀粉和MgSO4·7H2O为原料,NaOH为碱化剂,制备了交联淀粉负载氢氧化镁复合材料ISt-Mg(OH)2,采用FTIR、SEM、EDS、XRD对其进行了表征,并将其用于对模拟废水中Cu2+的吸附去除,考察了ISt-Mg(OH)2投加量、pH、Cu2+初始浓度等因素对ISt-Mg(OH)2吸附Cu2+性能的影响。结果表明,当Cu2+质量浓度为20 mg/L,pH=5.32,ISt-Mg(OH)2投加量为300 mg/L,吸附温度为25 oC时,Cu2+的去除率可达91.7%。吸附等温线拟合结果表明,ISt-Mg(OH)2对水中Cu2+的吸附过程符合Langumir吸附模型,为单分子层吸附过程,在25 oC时,拟合饱和吸附量为82.78 mg/g。吸附动力学数据拟合结果表明,吸附过程符合准二级动力学模型,属于化学吸附。将ISt-Mg(OH)2应用于处理Cu2+质量浓度15.20 mg/L、pH=5.45的电镀废水时,在其投加量为100 mg/L时,Cu2+去除率可达90%以上,具有良好的应用前景。

关键词: 交联淀粉, 氢氧化镁, 重金属离子, 吸附, 吸附机理
