ICPB技术及其去除废水中多环芳烃的研究进展

doi:10.19965/j.cnki.iwt.2022-0818

摘要/Abstract

摘要：

多环芳烃（PAHs）是难降解有机污染物之一，如不妥善处理会对生态环境造成影响，严重威胁人类健康。光催化与生物降解紧密耦合（ICPB）技术集合了光催化与生物降解的优点，可提高对难降解污染物的去除率，降低中间产物毒性，具有操作简单、能耗低、处理效率高等优点。归纳了ICPB技术的技术原理、发展及其在去除废水中PAHs方面的应用，总结了不同类型PAHs在不同反应体系下可能的降解途径，提出了目前针对ICPB技术研究中仍未解决的科学问题，并对未来发展进行了展望。通过进一步研究ICPB技术的作用机制并加快新型光催化剂的研究、筛选获得对光催化环境适应性强的微生物，将有效拓展该技术在实际大规模废水处理中的应用前景。

关键词: 光催化与生物降解紧密耦合技术, 多环芳烃, 降解途径

Abstract:

Polycyclic aromatic hydrocarbons（PAHs） are one kind of refractory organic pollutants. PAHs can affect biological environment and seriously threat human health if they are not treated properly. Intimate coupling photocatalysis and biodegradation（ICPB） technology combines the advantages of photocatalysis and biodegradation，which can improve the removal rate of refractory pollutants and reduce the toxicity of intermediate products. ICPB technology also has the advantages of easy operation，low energy consumption and high treatment efficiency. The mechanism，development and applications of ICPB technology in PAHs removal were reviewed. The possible degradation pathways of different PAHs under different reaction systems were also summarized. The unsolved scientific issues about ICPB technology were proposed and the future development was prospected. By further studying the mechanism of ICPB technology，accelerating the research of new photocatalysts and selecting microorganisms with strong adaptability to the photocatalytic environment，the application prospect of this technology in actual large-scale wastewater treatment will be effectively expanded.

Key words: intimate coupling photocatalysis and biodegradation（ICPB） technology, polycyclic aromatic hydrocarbons（PAHs）, degradation pathway

中图分类号:

X703

穆雨彤, 曹浩然, 朱博文, 麦智源, 韩克强, 张军, 王素蕾, 张多英. ICPB技术及其去除废水中多环芳烃的研究进展[J]. 工业水处理, 2023, 43(10): 9-15.

Yutong MU, Haoran CAO, Bowen ZHU, Zhiyuan MAI, Keqiang HAN, Jun ZHANG, Sulei WANG, Duoying ZHANG. Research progress on ICPB technology and its application in removing polycyclic aromatic hydrocarbons from sewage[J]. Industrial Water Treatment, 2023, 43(10): 9-15.

https://www.iwt.cn/CN/Y2023/V43/I10/9

图/表 5

参考文献 46

1	LIU Hang， WANG Chengyin， WANG Guoxiu. Photocatalytic advanced oxidation processes for water treatment：Recent advances and perspective［J］. Chemistry，an Asian Journal，2020，15（20）：3239-3253. doi:10.1002/asia.202000895
2	ZHANG Minna， TANG Zhenwu， YIN Hongmin，et al. Concentrations，distribution and risk of polycyclic aromatic hydrocarbons in sediments from seven major river basins in China over the past 20 years［J］. Journal of Environmental Management，2021，280：111717. doi:10.1016/j.jenvman.2020.111717
3	丁蕊，赵峰. 光催化耦合微生物同步降解污染物［J］. 化学进展，2017，29（9）：1154-1158. doi:10.7536/PC170414
	DING Rui， ZHAO Feng. Intimate coupling of photocatalysis and biodegradation to synchronously degrade pollutants［J］. Progress in Chemistry，2017，29（9）：1154-1158. doi:10.7536/PC170414
4	XIONG Jianhua， GUO Shuocheng， ZHAO Tianyu，et al. Degradation of methylene blue by intimate coupling photocatalysis and biodegradation with bagasse cellulose composite carrier［J］. Cellulose，2020，27（6）：3391-3404. doi:10.1007/s10570-020-02995-0
5	CHEN Shan， YUAN Mingzhe， FENG Wenbo，et al. Catalytic degradation mechanism of sulfamethazine via photosynergy of monoclinic BiVO₄ and microalgae under visible-light irradiation［J］. Water Research，2020，185：116220. doi:10.1016/j.watres.2020.116220
6	ZHONG Nianbing， YUAN Jilin， LUO Yihao，et al. Intimately coupling photocatalysis with phenolics biodegradation and photosynthesis［J］. Chemical Engineering Journal，2021，425：130666. doi:10.1016/j.cej.2021.130666
7	QIN Zhirui， ZHAO Zhenhua， JIAO Wentao，et al. Coupled photocatalytic-bacterial degradation of pyrene：Removal enhancement and bacterial community responses［J］. Environmental Research，2020，183：109135. doi:10.1016/j.envres.2020.109135
8	QIN Zhirui， ZHAO Zhenhua， JIAO Wentao，et al. Phenanthrene removal and response of bacterial community in the combined system of photocatalysis and PAH-degrading microbial consortium in laboratory system［J］. Bioresource Technology，2020，301：122736. doi:10.1016/j.biortech.2020.122736
9	GUO Qing， ZHOU Chuanyao， MA Zhibo，et al. Fundamentals of TiO₂ photocatalysis：Concepts，mechanisms，and challenges［J］. Advanced Materials，2019，31（50）：1901997. doi:10.1002/adma.201901997
10	DASS S， MUNEER M， GOPIDAS K R. Photocatalytic degradation of wastewater pollutants. Titanium-dioxide-mediated oxidation of polynuclear aromatic hydrocarbons［J］. Journal of Photochemistry and Photobiology A：Chemistry，1994，77（1）：83-88. doi:10.1016/1010-6030(94)80011-1
11	REN Guangmin， HAN Hongtao， WANG Yixuan，et al. Recent advances of photocatalytic application in water treatment：A review［J］. Nanomaterials，2021，11（7）：1804. doi:10.3390/nano11071804
12	LONG Zeqing， LI Qiangang， WEI Ting，et al. Historical development and prospects of photocatalysts for pollutant removal in water［J］. Journal of Hazardous Materials，2020，395：122599. doi:10.1016/j.jhazmat.2020.122599
13	田倩，吕勇，李晨光，等. g-C₃N₄的制备及其光催化降解诺氟沙星的机理及产物毒性研究［J］. 工业水处理，2022，42（11）：84-93.
	TIAN Qian， Yong LÜ， LI Chenguang，et al. Preparation of g-C₃N₄ and its photocatalytic degradation mechanism of norfloxacin and product toxicity evaluation［J］. Industrial Water Treatment，2022，42（11）：84-93.
14	MARSOLEK M D， TORRES C I， HAUSNER M，et al. Intimate coupling of photocatalysis and biodegradation in a photocatalytic circulating-bed biofilm reactor［J］. Biotechnology and Bioengineering，2008，101（1）：83-92. doi:10.1002/bit.21889
15	YU Mingliang， WANG Jiajia， TANG Lin，et al. Intimate coupling of photocatalysis and biodegradation for wastewater treatment：Mechanisms，recent advances and environmental applications［J］. Water Research，2020，175：115673. doi:10.1016/j.watres.2020.115673
16	刘宏，庞族族，石林，等. 光催化降解喹诺酮类抗生素的研究进展［J］. 工业水处理，2023，43（10）：34-41.
	LIU Hong， PANG Zuzu， SHI Lin，et al. Research progress on photocatalytic degradation of quinolone antibiotics［J］. Industrial Water Treatment，2023，43（10）：34-41.
17	GIMENO O， GARCÍA-ARAYA J F， BELTRÁN F J，et al. Removal of emerging contaminants from a primary effluent of municipal wastewater by means of sequential biological degradation-solar photocatalytic oxidation processes［J］. Chemical Engineering Journal，2016，290：12-20. doi:10.1016/j.cej.2016.01.022
18	MAHLALELA L C， CASADO C， MARUGÁN J，et al. Coupling biological and photocatalytic treatment of atrazine and tebuthiuron in aqueous solution［J］. Journal of Water Process Engineering，2021，40：101918. doi:10.1016/j.jwpe.2021.101918
19	PÉREZ-OSORIO G， DEL ROCÍO HERNÁNDEZ-GÓMEZ F， ARRIOLA-MORALES J，et al. Blue dye degradation in an aqueous medium by a combined photocatalytic and bacterial biodegradation process［J］. Turkish Journal of Chemistry，2020，44（1）：180-193. doi:10.3906/kim-1902-33
20	ZHOU Dandan， XU Zhengxue， DONG Shanshan，et al. Intimate coupling of photocatalysis and biodegradation for degrading phenol using different light types：Visible light vs. UV light［J］. Environmental Science & Technology，2015，49（13）：7776-7783. doi:10.1021/acs.est.5b00989
21	XIONG Houfeng， ZOU Donglei， ZHOU Dandan，et al. Enhancing degradation and mineralization of tetracycline using intimately coupled photocatalysis and biodegradation（ICPB）［J］. Chemical Engineering Journal，2017，316：7-14. doi:10.1016/j.cej.2017.01.083
22	XIONG Houfeng， DONG Shuangshi， ZHANG Jun，et al. Roles of an easily biodegradable co-substrate in enhancing tetracycline treatment in an intimately coupled photocatalytic-biological reactor［J］. Water Research，2018，136：75-83. doi:10.1016/j.watres.2018.02.061
23	YASMIN C， LOBNA E， MOUNA M，et al. New trend of Jebel Chakir landfill leachate pre-treatment by photocatalytic TiO₂/Ag nanocomposite prior to fermentation using Candida tropicalis strain［J］. International Biodeterioration & Biodegradation，2020，146：104829. doi:10.1016/j.ibiod.2019.104829
24	ZHANG Huanjun， LIU Zhehao， LI Yi，et al. Intimately coupled TiO₂/g-C₃N₄ photocatalysts and in situ cultivated biofilms enhanced nitrate reduction in water［J］. Applied Surface Science，2020，503：144092. doi:10.1016/j.apsusc.2019.144092
25	ZUO Wenlu， ZHANG Lei， ZHANG Zhidong，et al. Degradation of organic pollutants by intimately coupling photocatalytic materials with microbes：A review［J］. Critical Reviews in Biotechnology，2021，41（2）：273-299. doi:10.1080/07388551.2020.1869689
26	WEN Donghui， LI Guozheng， XING Rui，et al. 2，4-DNT removal in intimately coupled photobiocatalysis：The roles of adsorption，photolysis，photocatalysis，and biotransformation［J］. Applied Microbiology & Biotechnology，2012，95：263-272. doi:10.1007/s00253-011-3692-6
27	LI Guozheng， PARK S， RITTMANN B E. Developing an efficient TiO₂-coated biofilm carrier for intimate coupling of photocatalysis and biodegradation［J］. Water Research，，2012， 46（19）：6489-6496. doi:10.1016/j.watres.2012.09.029
28	XIONG Jianhua， GUO Shuocheng，ZHAO，Tianyu，et al. Degradation of methylene blue by intimate coupling photocatalysis and biodegradation with bagasse cellulose composite carrier［J］. Cellulose，2020，27（6）：3391-3401. doi:10.1007/s10570-020-02995-0
29	ZHANG Xinying， WU Yan， XIAO Gao，et al. Simultaneous photocatalytic and microbial degradation of dye-containing wastewater by a novel g-C₃N₄-P25/photosynthetic bacteria composite［J］. Plos One，2017，12（3）：e0172747. doi:10.1371/journal.pone.0172747
30	CHI Dechao， SUN Dandan， YANG Zekang，et al. Bifunctional nest-like self-floating microreactor for enhanced photothermal catalysis and biocatalysis［J］. Environmental Science：Nano，2019，6（12）：3551-3559. doi:10.1039/c9en00968j
31	LI Fuqiang， LAN Xuefang， WANG Lili，et al. An efficient photocatalyst coating strategy for intimately coupled photocatalysis and biodegradation（ICPB）：Powder spraying method［J］. Chemical Engineering Journal，2020，383：123092. doi:10.1016/j.cej.2019.123092
32	ABDEL-SHAFY H I， MANSOUR M S M. A review on polycyclic aromatic hydrocarbons：Source，environmental impact，effect on human health and remediation［J］. Egyptian Journal of Petroleum，2016，25（1）：107-123. doi:10.1016/j.ejpe.2015.03.011
33	SHARMA B M， MELYMUK L， BHARAT G K，et al. Spatial gradients of polycyclic aromatic hydrocarbons（PAHs） in air，atmospheric deposition，and surface water of the Ganges River Basin［J］. Science of the Total Environment，2018，627：1495-1504. doi:10.1016/j.scitotenv.2018.01.262
34	CHENG Hu， JI Rongting， BIAN Yongrong，et al. From macroalgae to porous graphitized nitrogen-doped biochars：Using aquatic biota to treat polycyclic aromatic hydrocarbons-contaminated water［J］. Bioresource Technology，2020，303：122947. doi:10.1016/j.biortech.2020.122947
35	BOJES H K， POPE P G. Characterization of EPA’s 16 priority pollutant polycyclic aromatic hydrocarbons（PAHs） in tank bottom solids and associated contaminated soils at oil exploration and production sites in Texas［J］. Regulatory Toxicology and Pharmacology，2007，47（3）：288-295. doi:10.1016/j.yrtph.2006.11.007
36	AL-TURKI A I. Microbial polycyclic aromatic hydrocarbons degradation in soil［J］. Research Journal of Environmental Toxicology，2009，3（1）：1-8. doi:10.3923/rjet.2009.1.8
37	CAI Haoyuan， SUN Lin， WANG Yameng，et al. Unprecedented efficient degradation of phenanthrene in water by intimately coupling novel ternary composite Mn₃O₄/MnO₂-Ag₃PO₄ and functional bacteria under visible light irradiation［J］. Chemical Engineering Journal，2019，369：1078-1092. doi:10.1016/j.cej.2019.03.143
38	WANG Can， LI Yunzhen， TAN Hang，et al. A novel microbe consortium，nano-visible light photocatalyst and microcapsule system to degrade PAHs［J］. Chemical Engineering Journal，2019，359：1065-1074. doi:10.1016/j.cej.2018.11.077
39	SIMIC M， MORTON Z， HOFFMAN M Z， EBERT M. Reaction of hydroxyl and O^- radicals with aromatic carboxylate anions in aqueous solutions［J］. The Journal of Physical Chemistry B，1973，77（9）：1117-1120. doi:10.1021/j100628a007
40	NGUYEN V H， PHAN THI L A， VAN LE Q，et al. Tailored photocatalysts and revealed reaction pathways for photodegradation of polycyclic aromatic hydrocarbons（PAHs） in water，soil and other sources［J］. Chemosphere，2020，260：127529. doi:10.1016/j.chemosphere.2020.127529
41	YANG Xiaolong， CAI Haoyuan， BAO Mutai，et al. Insight into the highly efficient degradation of PAHs in water over graphene oxide/Ag₃PO₄ composites under visible light irradiation［J］. Chemical Engineering Journal，2018，334：355-376. doi:10.1016/j.cej.2017.09.104
42	SHANKER U， JASSAL V， RANI M. Degradation of toxic PAHs in water and soil using potassium zinc hexacyanoferrate nanocubes［J］. Journal of Environmental Management，2017，204：337-348. doi:10.1016/j.jenvman.2017.09.015
43	GHOSAL D， GHOSH S， DUTTA T K，et al. Current state of knowledge in microbial degradation of polycyclic aromatic hydrocarbons（PAHs）：A review［J］. Frontiers in Microbiology，2016，7：1369. doi:10.3389/fmicb.2016.01369
44	MALLICK S， CHATTERJEE S， DUTTA T K. A novel degradation pathway in the assimilation of phenanthrene by Staphylococcus sp. strain PN/Y via meta-cleavage of 2-hydroxy-1-naphthoic acid：Formation of trans-2，3-dioxo-5-（2’-hydroxyphenyl）-pent-4-enoic acid［J］. Microbiology，2007，153（7）：2104-2115. doi:10.1099/mic.0.2006/004218-0
45	GHOSAL D， CHAKRABORTY J， KHARA P，et al. Degradation of phenanthrene via meta-cleavage of 2-hydroxy-1-naphthoic acid by Ochrobactrum sp. strain PWTJD［J］. FEMS Microbiology Letters，2010，313（2）：103-110. doi:10.1111/j.1574-6968.2010.02129.x
46	IMAM A， KUMAR SUMAN S， KANAUJIA P K，et al. Biological machinery for polycyclic aromatic hydrocarbons degradation：A review［J］. Bioresource Technology，2022，343：126121. doi:10.1016/j.biortech.2021.126121

目标降解物	材料组成	微生物	光源	目标污染物	降解效果	参考文献
酚类化合物	催化剂为TiO₂，载体为多孔陶瓷	活性污泥	紫外光（波长254 nm）	2，4-二硝基甲苯	60 h内2，4-二硝基甲苯降解率为78%	〔26〕
染料	催化剂为TiO₂，载体为聚氨酯海绵	活性污泥	紫外光（波长365 nm）	活性黑5	通过对载体的优化，提高了对活性黑5的光催化降解效率	〔27〕
染料	催化剂为TiO₂，载体为甘蔗渣纤维素海绵	活性污泥	紫外光（波长 254 nm）	亚甲基蓝	初始质量浓度为5 mg/L的亚甲基蓝6 h后脱除率为92.08%	〔28〕
染料	催化剂为g-C₃N₄-TiO₂（g-C₃N₄-P25），载体为海藻酸钙珠	光合细菌红螺菌属（Rhodospirillum）	卤素灯（波长 530 nm）	活性艳红X-3b	初始质量浓度为50 mg/L的活性艳红X-3b在96 h后的去除率为94%	〔29〕
抗生素类	催化剂为Ag修饰的单晶黑色TiO₂纳米片，载体为大孔聚氨酯泡沫	活性污泥	太阳光	头孢菌素	光照10 h头孢菌素降解率达96.1%	〔30〕
抗生素类	催化剂为BiOCl/Bi₂WO₆/Bi三元复合材料，载体为聚氨酯海绵	活性污泥	氙灯（300 W，波长420~800 nm）	盐酸四环素	10 h后盐酸四环素降解率可达97.2%	〔31〕

目标降解物	材料组成	微生物	光源	目标污染物	降解效果	参考文献
酚类化合物	催化剂为TiO₂，载体为多孔陶瓷	活性污泥	紫外光（波长254 nm）	2，4-二硝基甲苯	60 h内2，4-二硝基甲苯降解率为78%	〔26〕
染料	催化剂为TiO₂，载体为聚氨酯海绵	活性污泥	紫外光（波长365 nm）	活性黑5	通过对载体的优化，提高了对活性黑5的光催化降解效率	〔27〕
染料	催化剂为TiO₂，载体为甘蔗渣纤维素海绵	活性污泥	紫外光（波长 254 nm）	亚甲基蓝	初始质量浓度为5 mg/L的亚甲基蓝6 h后脱除率为92.08%	〔28〕
染料	催化剂为g-C₃N₄-TiO₂（g-C₃N₄-P25），载体为海藻酸钙珠	光合细菌红螺菌属（Rhodospirillum）	卤素灯（波长 530 nm）	活性艳红X-3b	初始质量浓度为50 mg/L的活性艳红X-3b在96 h后的去除率为94%	〔29〕
抗生素类	催化剂为Ag修饰的单晶黑色TiO₂纳米片，载体为大孔聚氨酯泡沫	活性污泥	太阳光	头孢菌素	光照10 h头孢菌素降解率达96.1%	〔30〕
抗生素类	催化剂为BiOCl/Bi₂WO₆/Bi三元复合材料，载体为聚氨酯海绵	活性污泥	氙灯（300 W，波长420~800 nm）	盐酸四环素	10 h后盐酸四环素降解率可达97.2%	〔31〕
