利用微藻处理酿酒废水及资源化的研究进展

doi:10.19965/j.cnki.iwt.2022-0684

摘要/Abstract

摘要：

酒精饮料可以分为发酵酒精饮料和蒸馏酒两大类，随着酒精饮料产量的增加，酿酒过程产生的废水成为环境污染的主要来源之一，传统的废水处理工艺具有能耗高、操作和维护成本高以及二次污染的缺点。一种基于微藻的废水处理方式被认为具有净化废水、固定二氧化碳和实现资源回收的潜力，有望替代传统的废水处理方式。总结了利用微藻处理酿酒废水的研究进展，首先总结了不同酿造废水的特点，然后从净化机理、微藻处理方式、影响因子、培养系统等方面全面地介绍了微藻在酿酒废水处理中的研究应用。最后讨论了从废水中收获的微藻生物质在生物能源、动物饲料以及生物肥料方面的应用潜力，以及利用微藻处理酿酒废水技术的优势和挑战。

关键词: 酿酒废水, 废水处理, 微藻, 资源化应用

Abstract:

Alcohol beverages，including fermented alcoholic beverage and distilled spirit. An annual growing production of alcohol beverages occurs worldwide，and the wastewater produced by distillery industry has become one of the main sources of environmental pollution. Conventional treatments methods are characterized by high energy consumption，high operation and maintenance costs，and secondary pollution. A microalgae-based treatment is considered to have the potential to purify the wastewater，fix carbon dioxide，and realize resource recycling，and it is expected to replace traditional methods. Firstly，this paper summarizes the characteristics of different distillery wastewaters. Then，it comprehensively introduces the research and application of microalgae in distillery wastewater treatment including purify mechanism，microalgae treatment modes，influencing factors，and cultivation systems. In the last，this paper also discusses the potential application of microalgae biomass in biofuel，animal feed，and bio-fertilizers，as well as the advantages and challenges of using microalgae technology.

Key words: distillery wastewater, wastewater treatment, microalgae, application of resource recovery

中图分类号:

X703

黎崎均, 苏建, 张富勇, 苟梓希, 刘莉, 陈仕江, 袁春芳, 乔宗伟, 安明哲. 利用微藻处理酿酒废水及资源化的研究进展[J]. 工业水处理, 2023, 43(9): 59-71.

Qijun LI, Jian SU, Fuyong ZHANG, Zixi GOU, Li LIU, Shijiang CHEN, Chunfang YUAN, Zongwei QIAO, Mingzhe AN. A review on distillery wastewater treatment and resource recycling by microalgae[J]. Industrial Water Treatment, 2023, 43(9): 59-71.

https://www.iwt.cn/CN/Y2023/V43/I9/59

图/表 5

参考文献 101

1	RAVIKUMAR Y， RAZACK S A， YUN Junhua，et al. Recent advances in microalgae-based distillery wastewater treatment［J］. Environmental Technology & Innovation，2021，24：101839. doi:10.1016/j.eti.2021.101839
2	LOFRANO G， MERIC S. A comprehensive approach to winery wastewater treatment：A review of the state-of the-art［J］. Desalination and Water Treatment，2016，57（7）：3011-3028. doi:10.1080/19443994.2014.982196
3	SHAH M P， RODRIGUEZ-COUTO S. Microbial wastewater treatment［M］. Amsterdam：Elsevier，2019：195-236.
4	BHARAGAVA R N， CHOWDHARY P. Emerging and eco-friendly approaches for waste management［M］. Singapore：Springer Singapore，2019：50-70. doi:10.1007/978-981-10-8669-4
5	AMENORFENYO D K， HUANG Xianghu， ZHANG Yulei，et al. Microalgae brewery wastewater treatment：Potentials，benefits and the challenges［J］. International Journal of Environmental Research and Public Health，2019，16（11）：1910. doi:10.3390/ijerph16111910
6	祖军宁，粟一峰，王一旭，等. 白酒工业废水治理技术研究进展［J］. 中国资源综合利用，2020，38（10）：97-106. doi:10.3969/j.issn.1008-9500.2020.10.027
	ZU Junning， SU Yifeng， WANG Yixu，et al. Research progress of liquor industry wastewater treatment technology［J］. China Resources Comprehensive Utilization，2020，38（10）：97-106. doi:10.3969/j.issn.1008-9500.2020.10.027
7	LIU Xiaoya， HONG Yu. Microalgae-based wastewater treatment and recovery with biomass and value-added products：Abrief review［J］. Current Pollution Reports，2021，7（2）：227-245. doi:10.1007/s40726-021-00184-6
8	NAGARAJAN D， LEE D J， CHEN C Y，et al. Resource recovery from wastewaters using microalgae-based approaches：A circular bioeconomy perspective［J］. Bioresource Technology，2020，302：122817. doi:10.1016/j.biortech.2020.122817
9	MOHD UDAIYAPPAN A F， HASAN H ABU， TAKRIFF M S，et al. A review of the potentials，challenges and current status of microalgae biomass applications in industrial wastewater treatment［J］. Journal of Water Process Engineering，2017，20：8-21. doi:10.1016/j.jwpe.2017.09.006
10	SHARMA G K， KHAN S A， SHRIVASTAVA M，et al. Circular economy fertilization：Phycoremediated algal biomass as biofertilizers for sustainable crop production［J］. Journal of Environmental Management，2021，287：112295. doi:10.1016/j.jenvman.2021.112295
11	KRISHNAMOORTHY S， PREMALATHA M， VIJAYASEKARAN M. Characterization of distillery wastewater：An approach to retrofit existing effluent treatment plant operation with phycoremediation［J］. Journal of Cleaner Production，2017，148：735-750. doi:10.1016/j.jclepro.2017.02.045
12	AMENORFENYO D K， HUANG Xianghu， LI Changling，et al. A review of microalgae and other treatment methods of distillery wastewater［J］. Water and Environment Journal，2020，34（S1）：988-1002. doi:10.1111/wej.12552
13	TURON V， TRABLY E， FAYET A，et al. Raw dark fermentation effluent to support heterotrophic microalgae growth：Microalgae successfully outcompete bacteria for acetate［J］. Algal Research，2015，12：119-125. doi:10.1016/j.algal.2015.08.011
14	TURON V， TRABLY E， FOUILLAND E，et al. Potentialities of dark fermentation effluents as substrates for microalgae growth：A review［J］. Process Biochemistry，2016，51（11）：1843-1854. doi:10.1016/j.procbio.2016.03.018
15	CHOI H J. Parametric study of brewery wastewater effluent treatment using Chlorella vulgaris microalgae［J］. Environmental Engineering Research，2016，21（4）：401-408. doi:10.4491/eer.2016.024
16	GUPTA S， PAWAR S B， PANDEY R A. Current practices and challenges in using microalgae for treatment of nutrient rich wastewater from agro-based industries［J］. Science of the Total Environment，2019，687：1107-1126. doi:10.1016/j.scitotenv.2019.06.115
17	PEREZ-GARCIA O， ESCALANTE F M E， DE-BASHAN L E，et al. Heterotrophic cultures of microalgae：Metabolism and potential products［J］. Water Research，2011，45（1）：11-36. doi:10.1016/j.watres.2010.08.037
18	CASAL C， CUARESMA M， VEGA J M，et al. Enhanced productivity of a lutein-enriched novel acidophile microalga grown on urea［J］. Marine Drugs，2010，9（1）：29-42. doi:10.3390/md9010029
19	GUPTA N， KHARE P， SINGH D P. Nitrogen-dependent metabolic regulation of lipid production in microalga Scenedesmus vacuolatus ［J］. Ecotoxicology and Environmental Safety，2019，174：706-713. doi:10.1016/j.ecoenv.2019.03.035
20	EMPARAN Q， HARUN R， DANQUAH M K. Role of phycoremediation for nutrient removal from wastewaters：A review［J］. Applied Ecology and Environmental Research，2019，17（1）：889-915. doi:10.15666/aeer/1701_889915
21	WANG Jinghan， ZHANG Tianyuan， Guohua DAO，et al. Microalgae-based advanced municipal wastewater treatment for reuse in water bodies［J］. Applied Microbiology and Biotechnology，2017，101（7）：2659-2675. doi:10.1007/s00253-017-8184-x
22	SONG Chunfeng， HU Xiaofang， LIU Zhengzheng，et al. Combination of brewery wastewater purification and CO₂ fixation with potential value-added ingredients production via different microalgae strains cultivation［J］. Journal of Cleaner Production，2020，268：122332. doi:10.1016/j.jclepro.2020.122332
23	LIU Cuixia， SUBASHCHANDRABOSE S， MING Hui，et al. Phycoremediation of dairy and winery wastewater using Diplosphaera sp.MM1［J］. Journal of Applied Phycology，2016，28（6）：3331-3341. doi:10.1007/s10811-016-0894-4
24	KRISHNAMOORTHY S， MANICKAM P， MUTHUKARUPPAN V.Evaluation of distillery wastewater treatability in a customized photobioreactor using blue-green microalgae-Laboratory and outdoor study［J］. Journal of Environmental Management，2019，234：412-423. doi:10.1016/j.jenvman.2019.01.014
25	LI Feng， AMENORFENYO D K， ZHANG Yulei，et al. Cultivation of Chlorella vulgaris in membrane-treated industrial distillery wastewater：Growth and wastewater treatment［J］. Frontiers in Environmental Science，2021，9：770633. doi:10.3389/fenvs.2021.770633
26	李攀荣，邹长伟，万金保，等. 微藻在废水处理中的应用研究［J］. 工业水处理，2016，36（5）：5-9. doi:10.11894/1005-829x.2016.36(5).005
	LI Panrong， ZOU Changwei， WAN Jinbao，et al. Research of micro algae processing wastewater［J］. Industrial Water Treatment，2016，36（5）：5-9. doi:10.11894/1005-829x.2016.36(5).005
27	HIGGINS B T， GENNITY I， FITZGERALD P S，et al. Algal-bacterial synergy in treatment of winery wastewater［J］. Npj Clean Water，2018，1：6. doi:10.1038/s41545-018-0005-y
28	PAPADOPOULOS K P， ECONOMOU C N， DAILIANIS S，et al. Brewery wastewater treatment using cyanobacterial-bacterial settleable aggregates［J］. Algal Research，2020，49：101957. doi:10.1016/j.algal.2020.101957
29	LING Jiayin，NIP S， CHEOK W L，et al. Lipid production by a mixed culture of oleaginous yeast and microalga from distillery and domestic mixed wastewater［J］. Bioresource Technology，2014，173：132-139. doi:10.1016/j.biortech.2014.09.047
30	DIAS C， GOUVEIA L， SANTOS J A L，et al. Rhodosporidium toruloides and tetradesmus obliquus populations dynamics in symbiotic cultures，developed in brewery wastewater，for lipid production［J］. Current Microbiology，2022，79（2）：40. doi:10.1007/s00284-021-02683-7
31	DIAS C， GOUVEIA L， SANTOS J A L，et al. Using flow cytometry to monitor the stress response of yeast and microalgae populations in mixed cultures developed in brewery effluents［J］. Journal of Applied Phycology，2020，32（6）：3687-3701. doi:10.1007/s10811-020-02236-8
32	DIAS C， REIS A， SANTOS J A L，et al. Primary brewery wastewater as feedstock for the yeast Rhodosporidium toruloides and the microalga Tetradesmus obliquus mixed cultures with lipid production［J］. Process Biochemistry，2022，113：71-86. doi:10.1016/j.procbio.2021.12.019
33	HAN Xiaoxuan， HU Xiaofang， YIN Qingrong，et al. Intensification of brewery wastewater purification integrated with CO₂ fixation via microalgae co-cultivation［J］. Journal of Environmental Chemical Engineering，2021，9（4）：105710. doi:10.1016/j.jece.2021.105710
34	SPENNATI E， MIRIZADEH S， CASAZZA A A，et al. Chlorella vulgaris and Arthrospira platensis growth in a continuous membrane photobioreactor using industrial winery wastewater［J］. Algal Research，2021，60：102519. doi:10.1016/j.algal.2021.102519
35	SPENNATI E， CASAZZA A， CONVERTI A. Winery wastewater treatment by microalgae to produce low-cost biomass for energy production purposes［D］. Genoa：University of Genoa，2020. doi:10.3390/en13102490
36	BHOLA V， SWALAHA F， RANJITH KUMAR R，et al. Overview of the potential of microalgae for CO₂ sequestration［J］. International Journal of Environmental Science and Technology，2014，11（7）：2103-2118. doi:10.1007/s13762-013-0487-6
37	KALOUDAS D， PAVLOVA N， PENCHOVSKY R. Phycoremediation of wastewater by microalgae：A review［J］. Environmental Chemistry Letters，2021，19（4）：2905-2920. doi:10.1007/s10311-021-01203-0
38	GETTE-BOUVAROT M， MERMILLOD-BLONDIN F， LEMOINE D，et al. The potential control of benthic biofilm growth by macrophytes：A mesocosm approach［J］. Ecological Engineering，2015，75：178-186. doi:10.1016/j.ecoleng.2014.12.001
39	NAVARRO-LÓPEZ E， RUÍZ-NIETO A， FERREIRA A，et al. Biostimulant potential of scenedesmus obliquus grown in brewery wastewater［J］. Molecules（Basel，Switzerland），2020，25（3）：E664. doi:10.3390/molecules25030664
40	FERREIRA A， RIBEIRO B， MARQUES P A S S，et al. Scenedesmus obliquus mediated brewery wastewater remediation and CO₂ biofixation for green energy purposes［J］. Journal of Cleaner Production，2017，165：1316-1327. doi:10.1016/j.jclepro.2017.07.232
41	FERREIRA A， RIBEIRO B， FERREIRA A F，et al. Scenedesmus obliquus microalga-based biorefinery-from brewery effluent to bioactive compounds，biofuels and biofertilizers-aiming at a circular bioeconomy［J］. Biofuels，Bioproducts and Biorefining，2019，13（5）：1169-1186. doi:10.1002/bbb.2032
42	MATA T M， MELO A C， SIMÕES M，et al. Parametric study of a brewery effluent treatment by microalgae Scenedesmus obliquus ［J］. Bioresource Technology，2012，107：151-158. doi:10.1016/j.biortech.2011.12.109
43	MARCHÃO L， SILVA T L， GOUVEIA L，et al. Microalgae-mediated brewery wastewater treatment：Effect of dilution rate on nutrient removal rates，biomass biochemical composition，and cell physiology［J］. Journal of Applied Phycology，2018，30（3）：1583-1595. doi:10.1007/s10811-017-1374-1
44	MARCHÃO L， FERNANDES J R， SAMPAIO A，et al. Microalgae and immobilized TiO₂/UV-A LEDs as a sustainable alternative for winery wastewater treatment［J］. Water Research，2021，203：117464. doi:10.1016/j.watres.2021.117464
45	YIRGU Z， LETA S， HUSSEN A，et al. Nutrient removal and carbohydrate production potential of indigenous Scenedesmus sp. grown in anaerobically digested brewery wastewater［J］. Environmental Systems Research，2020，9：1-14. doi:10.1186/s40068-020-00201-5
46	YIRGU Z， LETA S， HUSSEN A，et al. Optimization of microwave-assisted carbohydrate extraction from indigenous Scenedesmus sp.grown in brewery effluent using response surface methodology［J］. Heliyon，2021，7（5）：e07115. doi:10.1016/j.heliyon.2021.e07115
47	YIRGU Z， LETA S， HUSSEN A，et al. Pretreatment and optimization of reducing sugar extraction from indigenous microalgae grown on brewery wastewater for bioethanol production［J］. Biomass Conversion and Biorefinery，2021：1-15.
48	AVILA R， JUSTO Á， CARRERO E，et al. Water resource recovery coupling microalgae wastewater treatment and sludge co-digestion for bio-wastes valorisation at industrial pilot-scale［J］. Bioresource Technology，2022，343：126080. doi:10.1016/j.biortech.2021.126080
49	LUTZU G A， ZHANG Wei， LIU Tianzhong. Feasibility of using brewery wastewater for biodiesel production and nutrient removal by Scenedesmus dimorphus ［J］. Environmental Technology，2016，37（12）：1568-1581. doi:10.1080/09593330.2015.1121292
50	刘锦上，萧铭明，黄翔鹄，等. CO₂体积浓度对酒精废水培养微藻及其净化效果的影响［J］. 渔业现代化，2020，47（2）：42-51. doi:10.3969/j.issn.1007-9580.2020.02.006
	LIU Jinshang， XIAO Mingming， HUANG Xianghu，et al. Effect of CO₂ volume concentration on microalgae cultured in alcohol wastewater and its purification［J］. Fishery Modernization，2020，47（2）：42-51. doi:10.3969/j.issn.1007-9580.2020.02.006
51	FAROOQ W， LEE Y C， RYU B G，et al. Two-stage cultivation of two Chlorella sp. strains by simultaneous treatment of brewery wastewater and maximizing lipid productivity［J］. Bioresource Technology，2013，132：230-238. doi:10.1016/j.biortech.2013.01.034
52	DE J RAPOSO M F， OLIVEIRA S E， CASTRO P M，et al. On the utilization of microalgae for brewery effluent treatment and possible applications of the produced biomass［J］. Journal of the Institute of Brewing，2010，116（3）：285-292. doi:10.1002/j.2050-0416.2010.tb00433.x
53	SOLEYMANI ROBATI S M， NOSRATI M， GHANATI F，et al. Increase in lipid productivity and photosynthetic activities during distillery wastewater decolorization by Chlorella vulgaris cultures［J］. Applied Microbiology and Biotechnology，2021，105（8）：3339-3351. doi:10.1007/s00253-021-11233-x
54	QUINTERO-DALLOS V， GARCÍA-MARTÍNEZ J B， CONTRERAS-ROPERO J E，et al. Vinasse as a sustainable medium for the production of Chlorella vulgaris UTEX 1803［J］. Water，2019，11（8）：1526. doi:10.3390/w11081526
55	DARPITO C， SHIN W S， JEON S，et al. Cultivation of Chlorella protothecoides in anaerobically treated brewery wastewater for cost-effective biodiesel production［J］. Bioprocess and Biosystems Engineering，2015，38（3）：523-530. doi:10.1007/s00449-014-1292-4
56	SOLOVCHENKO A， POGOSYAN S， CHIVKUNOVA O，et al. Phycoremediation of alcohol distillery wastewater with a novel Chlorella sorokiniana strain cultivated in a photobioreactor monitored on-line via chlorophyll fluorescence［J］. Algal Research，2014，6：234-241. doi:10.1016/j.algal.2014.01.002
57	SANKARAN K， PREMALATHA M. Nutrients uptake from anaerobically digested distillery wastewater by Spirulina sp. under xenon lamp illumination［J］. Journal of Water Process Engineering，2018，25：295-300. doi:10.1016/j.jwpe.2018.08.014
58	王钰舟，杨雷，张景来，等. 利用啤酒废水培养极大螺旋藻［J］. 化工环保，2014，34（3）：257-261. doi:10.3969/j.issn.1006-1878.2014.03.013
	WANG Yuzhou， YANG Lei， ZHANG Jinglai，et al. Culture of Spirulina maxima using brewery wastewater［J］. Environmental Protection of Chemical Industry，2014，34（3）：257-261. doi:10.3969/j.issn.1006-1878.2014.03.013
59	刘玉环，史晓洁，巫小丹，等. 螺旋藻和菌-藻共生系统处理啤酒废水［J］. 环境工程学报，2014，8（1）：82-86.
	LIU Yuhuan， SHI Xiaojie， WU Xiaodan，et al. Brewery wastewater treatment by Spirulina platensis or fungi-algae symbiosis system［J］. Chinese Journal of Environmental Engineering，2014，8（1）：82-86.
60	柳青，张端，贺亚龙，等. 啤酒废水培养螺旋藻的研究［J］. 安徽农业科学，2014，42（1）：54-56. doi:10.3969/j.issn.0517-6611.2014.01.022
	LIU Qing， ZHANG Duan， HE Yalong，et al. Study on the cultivation of Spirulina with beer wastewater［J］. Journal of Anhui Agricultural Sciences，2014，42（1）：54-56. doi:10.3969/j.issn.0517-6611.2014.01.022
61	萧铭明，黄翔鹄，黄强，等. 温度、照度和接种量对钝顶螺旋藻去除酒精废水氮和磷的影响［J］. 广东海洋大学学报，2019，39（3）：54-60.
	XIAO Mingming， HUANG Xianghu， HUANG Qiang，et al. Effects of temperature，light intensity and inoculation volume on nitrogen and phosphorus removal from alcohol wastewater by Spirulina platensis ［J］. Journal of Guangdong Ocean University，2019，39（3）：54-60.
62	MATA T， SANTOS J， MENDES A，et al. Sustainability evaluation of biodiesel produced from microalgae Chlamydomonas sp. grown in brewery wastewater［J］. Chemical Engineering Transactions，2014，37：823-828.
63	余江，王萍，冉宗信，等. 莱茵衣藻Chlammydomonas reinhardtii净化酒糟废水研究［J］. 四川师范大学学报（自然科学版），2016，39（6）：900-904.
	YU Jiang， WANG Ping， RAN Zongxin，et al. Study on purification of vinasse wastewater by Chlamydomonas reinhardtii ［J］. Journal of Sichuan Normal University（Natural Science），2016，39（6）：900-904.
64	LIU Tingting， LUO Fei， WANG Zhenyao，et al. The enhanced biomass and lipid accumulation in Coccomyxa subellipsoidea with an integrated treatment strategy initiated by brewery effluent and phytohormones［J］. World Journal of Microbiology & Biotechnology，2018，34（2）：25. doi:10.1007/s11274-018-2408-9
65	KIM T H， LEE Y， HAN S H，et al. The effects of wavelength and wavelength mixing ratios on microalgae growth and nitrogen，phosphorus removal using Scenedesmus sp. for wastewater treatment［J］. Bioresource Technology，2013，130：75-80. doi:10.1016/j.biortech.2012.11.134
66	NZAYISENGA J C， FARGE X， GROLL S L，et al. Effects of light intensity on growth and lipid production in microalgae grown in wastewater［J］. Biotechnology for Biofuels，2020，13：4. doi:10.1186/s13068-019-1646-x
67	DOGARIS I， WELCH M， MEISER A，et al. A novel horizontal photobioreactor for high-density cultivation of microalgae［J］. Bioresource Technology，2015，198：316-324. doi:10.1016/j.biortech.2015.09.030
68	张权，常春，李斐，等. 微藻在废水中的高密度培养研究进展［J］. 现代化工，2016，36（11）：37-41.
	ZHANG Quan， CHANG Chun， LI Fei，et al. Progress of high-density culturing of microalgae in wastewater-based medium［J］. Modern Chemical Industry，2016，36（11）：37-41.
69	周浩媛，陈军，盛彦清. 微藻技术在污水处理中的应用与展望［J］. 环境科学与技术，2020，43（11）：160-171.
	ZHOU Haoyuan， CHEN Jun， SHENG Yanqing. Research progress of microalgae wastewater treatment technologies［J］. Environmental Science ＆ Technology，2020，43（11）：160-171.
70	DETCHANAMURTHY S. Studies on the effect of red，blue and white LED lights on the productivity of Chlorella vulgaris to treat dye industry effluent［J］. Advances in Biotechnology & Microbiology，2017，6（2）.DOI：10.19080/AIBM.2017.06.555682 .
71	VANDAMME D， FOUBERT I， FRAEYE I，et al. Flocculation of Chlorella vulgaris induced by high pH：Role of magnesium and calcium and practical implications［J］. Bioresource Technology，2012，105：114-119. doi:10.1016/j.biortech.2011.11.105
72	MATA T M， MELO A C， MEIRELES S，et al. Potential of microalgae scenedesmus obliquus grown in brewery wastewater for biodiesel production［J］. Chemical Engineering Transactions，2013，32：901-906.
73	LI Xin， HU Hongying， GAN Ke，et al. Effects of different nitrogen and phosphorus concentrations on the growth，nutrient uptake，and lipid accumulation of a freshwater microalga Scenedesmus sp.［J］. Bioresource Technology，2010，101（14）：5494-5500. doi:10.1016/j.biortech.2010.02.016
74	LI Kun， LIU Qiang， FANG Fan，et al. Microalgae-based wastewater treatment for nutrients recovery：A review［J］. Bioresource Technology，2019，291：121934. doi:10.1016/j.biortech.2019.121934
75	余江，陶红群，王亚婷，等. 磷受控对酿酒废水-微藻培育耦合体系的影响［J］. 西南交通大学学报，2019，54（3）：655-662.
	YU Jiang， TAO Hongqun， WANG Yating，et al. Influence of phosphorus control on coupling system of winery wastewater and microalgae cultivation［J］. Journal of Southwest Jiaotong University，2019，54（3）：655-662.
76	孟顺龙，裘丽萍，胡庚东，等. 氮磷比对两种蓝藻生长及竞争的影响［J］. 农业环境科学学报，2012，31（7）：1438-1444.
	MENG Shunlong， QIU Liping， HU Gengdong，et al. Effect of nitrogen and phosphorus ratios on growth and competition of two blue-green algae［J］. Journal of Agro-Environment Science，2012，31（7）：1438-1444.
77	邓祥元，丁婉婉，樊玲波，等. 2种微藻去除氮、磷能力的比较［J］. 吉林农业大学学报，2013，35（6）：694-698.
	DENG Xiangyuan， DING Wanwan， FAN Lingbo，et al. Comparative study on N and P removal ability of Chlorella pyrenoidosa and Scenedesmus obliquus ［J］. Journal of Jilin Agricultural University，2013，35（6）：694-698.
78	席晶晶. 不同氮磷比混合污水对两种微藻生长的影响及其机制探究［D］. 哈尔滨：哈尔滨工业大学，2020.
79	CARVALHO A P， MEIRELES L A， MALCATA F X. Microalgal reactors：A review of enclosed system designs and performances［J］. Biotechnology Progress，2006，22（6）：1490-1506. doi:10.1002/bp060065r
80	HUO Shuhao， WANG Zhongming， ZHU Shunni，et al. Cultivation of Chlorella zofingiensis in bench-scale outdoor ponds by regulation of pH using dairy wastewater in winter，South China［J］. Bioresource Technology，2012，121：76-82. doi:10.1016/j.biortech.2012.07.012
81	AYRE J M， MOHEIMANI N R， BOROWITZKA M A. Growth of microalgae on undiluted anaerobic digestate of piggery effluent with high ammonium concentrations［J］. Algal Research，2017，24：218-226. doi:10.1016/j.algal.2017.03.023
82	MONTALVO G E B， THOMAZ-SOCCOL V， VANDENBERGHE L P S，et al. Arthrospira maxima OF15 biomass cultivation at laboratory and pilot scale from sugarcane vinasse for potential biological new peptides production［J］. Bioresource Technology，2019，273：103-113. doi:10.1016/j.biortech.2018.10.081
83	MU OZ R， GONZALEZ-FERNANDEZ C. Microalgae-based biofuels and bioproducts［M］. Amsterdam：Elsevier，2017：1-44. doi:10.1016/c2015-0-05935-4
84	LU Weidong， WANG Zhongming， WANG Xuewei，et al. Cultivation of Chlorella sp. using raw dairy wastewater for nutrient removal and biodiesel production：Characteristics comparison of indoor bench-scale and outdoor pilot-scale cultures［J］. Bioresource Technology，2015，192：382-388. doi:10.1016/j.biortech.2015.05.094
85	YANG I S， SALAMA E S， KIM J O，et al. Cultivation and harvesting of microalgae in photobioreactor for biodiesel production and simultaneous nutrient removal［J］. Energy Conversion and Management，2016，117：54-62. doi:10.1016/j.enconman.2016.03.017
86	ACIÉN F G， GÓMEZ-SERRANO C， MORALES-AMARAL M M，et al. Wastewater treatment using microalgae：How realistic a contribution might it be to significant urban wastewater treatment？［J］. Applied Microbiology and Biotechnology，2016，100（21）：9013-9022. doi:10.1007/s00253-016-7835-7
87	MORALES-AMARAL M D M， GÓMEZ-SERRANO C， ACIÉN F G，et al. Outdoor production of Scenedesmus sp. in thin-layer and raceway reactors using centrate from anaerobic digestion as the sole nutrient source［J］. Algal Research，2015，12：99-108. doi:10.1016/j.algal.2015.08.020
88	GUPTA P L， LEE S M， CHOI H J. A mini review：photobioreactors for large scale algal cultivation［J］. World Journal of Microbiology and Biotechnology，2015，31（9）：1409-1417. doi:10.1007/s11274-015-1892-4
89	NORSKER N H， BARBOSA M J， VERMUË M H，et al. Microalgal production：A close look at the economics［J］. Biotechnology Advances，2011，29（1）：24-27. doi:10.1016/j.biotechadv.2010.08.005
90	VO H N P， NGO H H， GUO Wenshan，et al. A critical review on designs and applications of microalgae-based photobioreactors for pollutants treatment［J］. Science of the Total Environment，2019，651：1549-1568. doi:10.1016/j.scitotenv.2018.09.282
91	章真，刘晓军，陈夏，等. 微藻生物技术在碳中和的应用与展望［J］. 中国生物工程杂志，2022，42（S1）：160-173.
	ZHANG Zhen， LIU Xiaojun， CHEN Xia，et al. Application and prospect of microalgae biotechnology in carbon neutralization［J］. China Biotechnology，2022，42（S1）：160-173.
92	MASWANNA T， LINDBLAD P， MANEERUTTANARUNGROJ C. Improved biohydrogen production by immobilized cells of the green alga Tetraspora sp. CU2551 incubated under aerobic condition［J］. Journal of Applied Phycology，2020，32（5）：2937-2945. doi:10.1007/s10811-020-02184-3
93	MASWANNA T， PHUNPRUCH S， LINDBLAD P，et al. Enhanced hydrogen production by optimization of immobilized cells of the green alga Tetraspora sp. CU2551 grown under anaerobic condition［J］. Biomass and Bioenergy，2018，111：88-95. doi:10.1016/j.biombioe.2018.01.005
94	KUSMAYADI A， LEONG Y K， YEN H W，et al. Microalgae as sustainable food and feed sources for animals and humans：Biotechnological and environmental aspects［J］. Chemosphere，2021，271：129800. doi:10.1016/j.chemosphere.2021.129800
95	FUENTES-GRÜNEWALD C， IGNACIO GAYO-PELÁEZ J， NDOVELA V，et al. Towards a circular economy：A novel microalgal two-step growth approach to treat excess nutrients from digestate and to produce biomass for animal feed［J］. Bioresource Technology，2021，320：124349. doi:10.1016/j.biortech.2020.124349
96	HOLMAN B W B， KASHANI A， MALAU-ADULI A E O. Effects of Spirulina（Arthrospira platensis） supplementation level and basal diet on liveweight，body conformation and growth traits in genetically divergent Australian dual-purpose lambs during simulated drought and typical pasture grazing［J］. Small Ruminant Research，2014，120（1）：6-14. doi:10.1016/j.smallrumres.2014.04.014
97	边建文，崔岩，杨宋琪，等. 微藻生物肥料的农业应用研究进展［J］. 中国土壤与肥料，2020（5）：1-9. doi:10.11838/sfsc.1673-6257.19290
	BIAN Jianwen， CUI Yan， YANG Songqi，et al. Research progress in agricultural application of microalgae bio-fertilizer［J］. Soil and Fertilizer Sciences in China，2020（5）：1-9. doi:10.11838/sfsc.1673-6257.19290
98	胡洪营，李鑫. 利用污水资源生产微藻生物柴油的关键技术及潜力分析［J］. 生态环境学报，2010，19（3）：739-744. doi:10.3969/j.issn.1674-5906.2010.03.043
	HU Hongying， LI Xin. Analysis of key techniques and production potential of biodiesel production based on microalgae with wastewater as resources［J］. Ecology and Environmental Sciences，2010，19（3）：739-744. doi:10.3969/j.issn.1674-5906.2010.03.043
99	WANG Zichao， GAO Mengchun， WEI Junfeng，et al. Extracellular polymeric substances，microbial activity and microbial community of biofilm and suspended sludge at different divalent cadmium concentrations［J］. Bioresource Technology，2016，205：213-221. doi:10.1016/j.biortech.2016.01.067
100	HO S H， CHEN C Y， LEE D J，et al. Perspectives on microalgal CO₂-emission mitigation systems：A review［J］. Biotechnology Advances，2011，29（2）：189-198. doi:10.1016/j.biotechadv.2010.11.001
101	GUPTA S K，BUX F. Application of microalgae in wastewater treatment［M］. Singapore：Springer，2019：81-99. doi:10.1007/978-3-030-13909-4

参数	废水类型
参数	啤酒	葡萄酒	白酒	其他蒸馏酒
pH	3~12	3.5~12.4	3~7	4~4.6
BOD	1 200~3 600	3 250~13 400	2 800~35 000	25 000~35 000
COD	2 000~6 000	4 650~24 500	8 000~70 000	85 000~110 000
磷	10~15	—	25~4 000	1 500~2 200
TKN	25~80	1 350	120~1 200	4 200~4 800
TOC	—	2 674	—	40 000~42 000
TSS	2 901~3 000	485~1 259	500~3 500	4 500~7 000
TS	500~8 750	748~21 410	—	85 000~110 000
VFA	1 000~2 500	—	—	—
多酚	—	103~735	—	3 000~4 000

参数	废水类型
参数	啤酒	葡萄酒	白酒	其他蒸馏酒
pH	3~12	3.5~12.4	3~7	4~4.6
BOD	1 200~3 600	3 250~13 400	2 800~35 000	25 000~35 000
COD	2 000~6 000	4 650~24 500	8 000~70 000	85 000~110 000
磷	10~15	—	25~4 000	1 500~2 200
TKN	25~80	1 350	120~1 200	4 200~4 800
TOC	—	2 674	—	40 000~42 000
TSS	2 901~3 000	485~1 259	500~3 500	4 500~7 000
TS	500~8 750	748~21 410	—	85 000~110 000
VFA	1 000~2 500	—	—	—
多酚	—	103~735	—	3 000~4 000

参数	酒糟废水	发酵罐冷却水	发酵罐洗涤水	冷凝器冷却水	洗瓶水
色泽	深棕色	无色	无色	无色	无色
pH	4~4.5	6.26	5~5.5	6.8~7.8	7.45
TS	100 000	1 000~1 300	1 000~1 500	700~900	400
SS	10 000	220	400~600	80~200	100
BOD	45 000~60 000	100~110	500~600	70-80	5
COD	80 000~120 000	500~1 000	1 200~1 600	200~300	15

参数	酒糟废水	发酵罐冷却水	发酵罐洗涤水	冷凝器冷却水	洗瓶水
色泽	深棕色	无色	无色	无色	无色
pH	4~4.5	6.26	5~5.5	6.8~7.8	7.45
TS	100 000	1 000~1 300	1 000~1 500	700~900	400
SS	10 000	220	400~600	80~200	100
BOD	45 000~60 000	100~110	500~600	70-80	5
COD	80 000~120 000	500~1 000	1 200~1 600	200~300	15

属	种	废水来源	参考文献
Scenedesmus	Scenedesmus obliquus	啤酒、葡萄酒	〔39-44〕
	Scenedesmus sp.	啤酒、葡萄酒、蒸馏酒	〔23，33，45-48〕
	Scenedesmus dimorphus	啤酒	〔49〕
	Scenedesmus quadricauda	蒸馏酒	〔50〕
Chlorella	Chlorella vulgaris	啤酒、葡萄酒、蒸馏酒	〔15，25，34-35，44，50-54〕
	Chlorella sp.	啤酒、葡萄酒	〔22，29，33，48，51〕
	Chlorella protothecoides	啤酒	〔55〕
	Chlorella sorokiniana	啤酒、葡萄酒、蒸馏酒	〔27，33，56〕
	Chlorella pyrenoidosa	蒸馏酒	〔29〕
Arthrospira（Spirulina）	Spirulina sp.	啤酒、蒸馏酒	〔22，24，57〕
	Arthrospira（Spirulina） maxima	啤酒、葡萄酒	〔44，58〕
	Arthrospira platensis	啤酒、葡萄酒	〔34-35，50，59-61〕
Auxenochlorella	Auxenochlorella protothecoides	葡萄酒	〔44〕
Diplosphaera	Diplosphaera sp. MM1	葡萄酒	〔23〕
Chlamydomonas	Chlamydomonas sp.（SAG 9.98）	啤酒	〔62〕
Chlamydomonas	Chlamydomonas reinhardtii	蒸馏酒	〔63〕
Coccomyxa	Coccomyxa Subellipsoidea C-169	啤酒	〔64〕
Oscillatoria	Oscillatoria sp.	蒸馏酒	〔11〕
Leptolyngbya	Leptolyngbya sp.	啤酒	〔28〕
Auxenochlorella	Auxenochlorella protothecoides	葡萄酒	〔27〕
Tetradesmus	Tetradesmus obliquus	啤酒	〔30-32〕
